EQ… Panel-mounted instrument with moving-iron movement
Data sheet for EQ…: Datasheet (1)
Drawing(s) für EQ…: See data sheet
| AC current and voltage measurement | See data sheet |
| Design | Square in 48x48mm, 72x72mm, 96x96mm u. 144x144mm, see data sheet |
| Accuracy class | 1.5 according to EN 60 051 |
| Dimension | See data sheet |
| Protection class | Front face IP52, connections IP00 |
| Housing | Plastic, self-extinguishing (ULV94/V0)0) |
